resin solvent, composite solvent, polyester solvent, resin cleaner, polyester cleaner, composite cleaner





Polyester cleaning solvents

  Manufacture and use



iBiotec® FAST CLEAN ORANGE 100

solvent for resin manufacturers

 NON-FLAMMABLE, VOC-FREE

HUGE SETTLING POWER

RECYCLABLE, REUSABLE

HALOGEN-FREE, SULPHUR-FREE

SUBSTITUTE for NMP and NEP (CMR)





iBiotec® FAST CLEAN ORANGE 34

solvent for resin users

 SLIGHTLY FLAMMABLE

FAST EVAPORATION SPEED

RECYCLABLE, REUSABLE

HALOGEN-FREE, SULPHUR-FREE

SUBSTITUTE for ACETONE and MEK

REDUCED CONSUMPTION





Consult the technical sheets at the bottom of the page





Polyester resins are widely used according to their usages and implementation.

Unsaturated polyesters UP or UPR are included in several families. The most common are:

Aliphatic homopolymers PGA   PLA   PGL    PCL     PHA    PHB

Aliphatic copolyesters PEA  PBS

Semi-aromatic copolyesters FBT PTT  PEN (PET and PEC saturated thermoplastics)

Aromatic homo- and copolyesters Polyacrylates

Vinylester resins, occasionally called "polyester-epoxy hybrid resins" often have applications which are identical to polyester applications.

These resins have extensive applications:

For composites

resins for stratification

for automobile equipment

for moulds

for coating (encapsulation)

multi-purpose

for SML compression (sheet moulding compound)

for BMC injection (bulk moulding compound)

for MMC injection (mineral moulding compound)

for CIC (continuous impregnated compound)

for marine - stratification and top coating (gel coats)

For coating

Undercoating   primers, varnishes, lacquers, inks, adhesives, etc.

Top coating pain, lacquers, varnishes, etc.

Gel coats

The following implementation procedures are used for composites:

Contact moulding (spiked rollers)

Simultaneous spraying

Low pressure injection (transfer of RTM resin)

Vacuum, infusion, oven moulding

By filament winding

By SMC or BMC compression machines

Cleaning manufacturing pilots, implementation tools, machine environment, machines or fresh residual spots always require the use of solvents.

Note: Although the European Directive on Volatile Organic Compounds (VOC) has been challenged by virtue of its applicability by the Fibre-reinforced Plastics industry regarding the terminology of the stratification of wood and plastics (based on styrene emissions: reactive monomer, in which the unsaturated polyester is dissolved, but which copolymerises with the reactive sites of unsaturated polyester chains to form a three-dimensional solid known as thermosetting plastic), the regulatory framework for using cleaning solvents cannot be disputed.

The criteria and needs relating to the use of unsaturated polyester cleaning solvents are different depending on whether they involve:

RESIN PRODUCTION UNITS, RESIN MANUFACTURERS

normally ICPE (installations classified for environmental protection) concerned by the IED Directive, establishment of a SMP, limitation of VOC emissions, control and recycling of industrial waste. The solvents used must be quick to dissolve when cleaning tanks, reactors and mixers between two batches if there is no on-going sequence or when bleeding pipe or filling systems. This cleaning must be even more thorough when a hardener is manufactured after a resin, in the same pilot.

Typical solvents n-methyl-2-pyrrolidone (NMP), n-ethylpyrrolidone-2 (NEP) and gamma butyrolactone (GBL) give good results but are classed CMR (carcinogenic, mutagenic and toxic to reproduction).

IMPLEMENTATION UNITS or WORKSHOPS, APPLICATORS, USERS

of polyester resins, Applicators, Users

Acetone is very often used in this case. Contrary to the needs of producers, implementation requires mixing a resin and a hardener. The cleaning operation must take the same time as the TECAM gel (mix use duration).

More than 1 tonne of acetone, if stored or used, falls under SEVESO III and must be declared or a request for authorisation must be submitted to DREAL (Classified establishments inspection). The regulatory obligations therefore become the same in terms of the IED directive and the establishment of a SMP (solvent management plan).

Apart from being highly flammable CAT 2, acetone presents no toxic hazard.

Refer to INRS toxicity sheet no. 3 Acetone Case 67641, revised April 2016

  • Highly flammable Cat 2 flashpoint -18°C closed tank
  • Irritant, irritation of the skin and mucous membranes, severe ocular lesion Cat 2
  • Depression of the nervous system in high exposure
  • Neurological effects, headaches, vertigo or comas in certain convulsive cases
  • Digestive effects, nausea, vomiting, hematemesis
  • Specific toxicity for certain target organs
  • Narcotic effect Cat 3
  • Art. 4412-149 of the Labour Code OEL

RESTRICTIVE EVL  TWA 500 ppm  STEL 1000 ppm





                             Download the data sheet



TECHNICAL DATA SHEET

iBiotec® FAST CLEAN ORANGE 100

solvent for resin manufacturers





TYPICAL PHYSICAL-CHEMICAL PROPERTIES

 PROPERTIES

  STANDARDS

VALUES

UNITS

Appearance

  Visual

Clear

-

Colour

  Visual

Yellow

-

Smell

  Olfactory

Slight, orange

-

Density at 25°C

  NF EN ISO 12185

1.012

kg/m3

Refraction index

  ISO 5661

1.4380

-

Freezing point

  ISO 3016

-15

°C

Water solubility

  -

0

%

Kinematic viscosity at 40°C

  NF EN 3104

2.3

mm²/s

Acid index Ia

  EN 14104

<1

mg(KOH)/g

Iodine index

  NF EN 14111

0

gI2/100g

Water content

  NF ISO 6296

<0.001

%

Residue after evaporation

  NF T 30-084

0

%

PERFORMANCE CHARACTERISTICS

PROPERTIES

  STANDARDS

VALUES

UNITS

KB index

  ASTM D 1133

>200

-

Evaporation speed

  -

>3

hours

Surface tension at 20°C

  ISO 6295

34.5

dyne/cm

Copper blade corrosion 100 h at 40°C

  ISO 2160

1a

Measured value

Aniline point

  ISO 2977

nm

°C

FIRE SAFETY CHARACTERISTICS

PROPERTIES

  STANDARDS

VALUES

UNITS

Flashpoint (closed cup)

NF EN 22719

>100

°C

Autoignition point

  ASTM E 659

>200

°C

Lower Explosive Limit

  NF EN 1839

0.9

% (volume)

Upper Explosive Limit

  NF EN 1839

8.7

% (volume)

Explosive, oxidising agent, flammable, highly or extremely flammable substance content

  CLP Regulation

0

%

TOXICOLOGICAL CHARACTERISTICS

PROPERTIES

  STANDARDS

VALUES

UNITS

Anisidine index

  NF ISO 6885

<3

-

Peroxide index

  NF ISO 3960

nm

meq(O2)/kg

TOTOX (anisidine index+2x peroxide index)

  -

nm

-

CMR, irritant and corrosive substance content

  CLP Regulation

0

%

Residual methanol content from transesterification

  GC-MS

0

%

Emissions of hazardous compounds, CMR, irritants, corrosive at 100°C

  GC-MS

nm

%

ENVIRONMENTAL CHARACTERISTICS

PROPERTIES

  STANDARDS

VALUES

UNITS

Water hazard

WGK Germany

1

without hazard for water

class

Primary CEC biodegradability 21 days at 25°C

L 33 T82

>80

%

OECD easy biodegradability 301 A over 28 days

Disappearance of COD

ISO 7827

>80

%

OECD easy and ultimate biodegradability 301 D over 28 days

Biodegradation at 67 days

MITI amended

nm









TECHNICAL DATA SHEET

iBiotec® FAST CLEAN ORANGE 34

solvent for resin users



TYPICAL PHYSICAL-CHEMICAL PROPERTIES

 PROPERTIES

  STANDARDS

VALUES

UNITS

Appearance

  Visual

Clear

-

Colour

  Visual

Colourless

-

Smell

  Olfactory

Slight, orange

-

Density at 25°C

  NF EN ISO 12185

926

kg/m3

Refraction index

  ISO 5661

1.4010

-

Freezing point

  ISO 3016

-25

°C

Water solubility

  -

>80

%

Kinematic viscosity at 40°C

  NF EN 3104

1.2

mm²/s

Acid index Ia

  EN 14104

<1

mg(KOH)/g

Iodine index

  NF EN 14111

0

gI2/100g

Water content

  NF ISO 6296

<0.1

%

Residue after evaporation

  NF T 30-084

0

%

PERFORMANCE CHARACTERISTICS

PROPERTIES

  STANDARDS

VALUES

UNITS

KB index

  ASTM D 1133

>150

-

Evaporation speed

  -

8

minutes

Surface tension at 20°C

  ISO 6295

29.0

dyne/cm

Copper blade corrosion 100 h at 40°C

  ISO 2160

1a

Measured value

Aniline point

  ISO 2977

nm

°C

FIRE SAFETY CHARACTERISTICS

PROPERTIES

  STANDARDS

VALUES

UNITS

Flashpoint (closed cup)

NF EN 22719

34

°C

Autoignition point

  ASTM E 659

>200

°C

Lower Explosive Limit

  NF EN 1839

1.5

% (volume)

Upper Explosive Limit

  NF EN 1839

14.0

% (volume)

TOXICOLOGICAL CHARACTERISTICS

PROPERTIES

  STANDARDS

VALUES

UNITS

Anisidine index

  NF ISO 6885

<3

-

Peroxide index

  NF ISO 3960

nm

meq(O2)/kg

TOTOX (anisidine index+2x peroxide index)

  -

nm

-

CMR, irritant and corrosive substance content

  CLP Regulation

0

%

Residual methanol content from transesterification

  GC-MS

0

%

ENVIRONMENTAL CHARACTERISTICS

PROPERTIES

  STANDARDS

VALUES

UNITS

Water hazard

WGK Germany

1

without hazard for water

class

Primary CEC biodegradability 21 days at 25°C

L 33 T82

>70

%

OECD easy biodegradability 301 A over 28 days

Disappearance of COD

ISO 7827

>70

%

OECD easy and ultimate biodegradability 301 D over 28 days

Biodegradation at 67 days

MITI amended

72







PRESENTATIONS







Bidon 20 L





Safety solvents for cleaning polyester, epoxy, polyurethane and composite resins. Substitutes for NMP, NEP, acetone and methylene chloride. Which Safety Solvent to choose? To dissolve composites, polyester matrices, UPR, hybrids, epoxies, polyurethanes, Ibiotec formulator and manufacturer of technical solvents. Resin solvent, composite solvent, polyester solvent, resin cleaner, polyester cleaner, composite cleaner



Drum 200 L





Safety solvents for cleaning polyester, epoxy, polyurethane and composite resins. Substitutes for NMP, NEP, acetone and methylene chloride. Which Safety Solvent to choose? To dissolve composites, polyester matrices, UPR, hybrids, epoxies, polyurethanes, Ibiotec formulator and manufacturer of technical solvents. Resin solvent, composite solvent, polyester solvent, resin cleaner, polyester cleaner, composite cleaner



 GRV 1000 L





Safety solvents for cleaning polyester, epoxy, polyurethane and composite resins. Substitutes for NMP, NEP, acetone and methylene chloride. Which Safety Solvent to choose? To dissolve composites, polyester matrices, UPR, hybrids, epoxies, polyurethanes, Ibiotec formulator and manufacturer of technical solvents. Resin solvent, composite solvent, polyester solvent, resin cleaner, polyester cleaner, composite cleaner



iBiotec® FAST CLEAN ORANGE 100

solvent for resin manufacturers





Safety solvents for cleaning polyester, epoxy, polyurethane and composite resins. Substitutes for NMP, NEP, acetone and methylene chloride. Which Safety Solvent to choose? To dissolve composites, polyester matrices, UPR, hybrids, epoxies, polyurethanes, Ibiotec formulator and manufacturer of technical solvents. Resin solvent, composite solvent, polyester solvent, resin cleaner, polyester cleaner, composite cleaner

Washing manufacturing tanks between batches





Safety solvents for cleaning polyester, epoxy, polyurethane and composite resins. Substitutes for NMP, NEP, acetone and methylene chloride. Which Safety Solvent to choose? To dissolve composites, polyester matrices, UPR, hybrids, epoxies, polyurethanes, Ibiotec formulator and manufacturer of technical solvents. Resin solvent, composite solvent, polyester solvent, resin cleaner, polyester cleaner, composite cleaner

 Rinsing manufacturing units





Safety solvents for cleaning polyester, epoxy, polyurethane and composite resins. Substitutes for NMP, NEP, acetone and methylene chloride. Which Safety Solvent to choose? To dissolve composites, polyester matrices, UPR, hybrids, epoxies, polyurethanes, Ibiotec formulator and manufacturer of technical solvents. Resin solvent, composite solvent, polyester solvent, resin cleaner, polyester cleaner, composite cleaner

 Bleeding pipes

 ---

iBiotec® FAST CLEAN ORANGE 34

solvent for resin users

Safety solvents for cleaning polyester, epoxy, polyurethane and composite resins. Substitutes for NMP, NEP, acetone and methylene chloride. Which Safety Solvent to choose? To dissolve composites, polyester matrices, UPR, hybrids, epoxies, polyurethanes, Ibiotec formulator and manufacturer of technical solvents. Resin solvent, composite solvent, polyester solvent, resin cleaner, polyester cleaner, composite cleaner

Cleaning application tools, spikers, in stratification



Safety solvents for cleaning polyester, epoxy, polyurethane and composite resins. Substitutes for NMP, NEP, acetone and methylene chloride. Which Safety Solvent to choose? To dissolve composites, polyester matrices, UPR, hybrids, epoxies, polyurethanes, Ibiotec formulator and manufacturer of technical solvents. Resin solvent, composite solvent, polyester solvent, resin cleaner, polyester cleaner, composite cleaner

Cleaning polyester or epoxy gel coat application equipment

in shipbuilding or ship repairs
